Vibro-Meter TQ403 111-403-000-013 A1-B1-C036-D000-E100-F1-G098-H10 Proximity Transducer

TQ403 111-403-000-013 A1-B1-C036-D000-E100-F1-G098-H10 is a Vibro-Meter eddy-current proximity transducer with a 36 mm body, M20 × 1.5 thread and 10 m integral cable. It is used for non-contact displacement and vibration measurement with a matching EA403 / IQS900 chain.

TQ403 111-403-000-013 A1-B1-C036-D000-E100-F1-G098-H10 senses changes in proximity to a conductive target without mechanical contact. In the documented TQ403 / EA403 / IQS900 system, the complete measurement chain supports relative shaft displacement and vibration monitoring.

TQ403 111-403-000-013 A1-B1-C036-D000-E100-F1-G098-H10 has a B1 M20 × 1.5 body thread, C036 36 mm body and D000 0 mm unthreaded length. These manufacturer-defined mechanical dimensions identify the exact mounting configuration for this requested variant.

TQ403 111-403-000-013 A1-B1-C036-D000-E100-F1-G098-H10 has a 10 m integral cable (E100), a flexible protective hose without connector protection (F1), and a 9.8 m hose length (G098). The cable and protection arrangement are manufacturer-defined ordering options.

TQ403 111-403-000-013 A1-B1-C036-D000-E100-F1-G098-H10 has H10, designating a 10 m total measurement-system length. E100 also specifies a 10 m integral sensor cable; the EA403 cable and IQS900 conditioner must be matched to the documented chain configuration.

TQ403 111-403-000-013 A1-B1-C036-D000-E100-F1-G098-H10 uses A1, the standard-environment option rather than an Ex-certified option. Hazardous-area use requires appropriately certified sensor, EA403 cable and IQS900 conditioner options, so this exact A1 configuration should not be represented as Ex-rated.

TQ403 111-403-000-013 A1-B1-C036-D000-E100-F1-G098-H10 is the sensing element of a TQ403 proximity measurement system. A compatible EA403 extension cable and IQS900 signal conditioner form the remaining chain; match total length, target material and complete ordering codes to the installation.
