 /Siemens 6ES7288-2DR32-0AA0 SIMATIC S7-200 SMART EM DR32 32-Point Mixed Relay I/O Expansion Module
Siemens 6ES7288-2DR32-0AA0 SIMATIC S7-200 SMART EM DR32 32-Point Mixed Relay I/O Expansion Module
Siemens 6ES7288-1CR30-0AA1 SIMATIC S7-200 SMART CPU CR30s
Siemens 6ES7288-1CR30-0AA1 SIMATIC S7-200 SMART CPU CR30s

Siemens 6ES7288-2DR32-0AA0 SIMATIC S7-200 SMART EM DR32 32-Point Mixed Relay I/O Expansion Module

SIMATIC S7-200 SMART · EM DR32

6ES7288-2DR32-0AA0

The 6ES7288-2DR32-0AA0 is a Siemens SIMATIC S7-200 SMART EM DR32 mixed digital I/O module with 16 digital inputs and 16 relay outputs.

INPUTS16 DI
OUTPUTS16 DQ
OUTPUT TYPERELAY
POWER LOSS10 W
MANUFACTURERSiemens
CONDITION / WARRANTYOriginal New · One-Year Warranty
ISO CERTIFICATIONISO-Certified Product
VERIFICATION● Product photos and videos provided after inquiry
REQUEST A QUOTE
สอบถามตอนนี้
MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.
SEARCH MODELS
SIEMENS ● RELAY I/O MODULE
SIMATIC S7-200 SMART EXPANSION I/O

6ES7288-2DR32-0AA0

EM DR32

Mixed Digital I/O · 16 DI / 16 Relay DQ

MEASUREMENT ROLE
6ES7288-2DR32-0AA0 is a SIMATIC S7-200 SMART mixed digital I/O expansion module with 16 digital inputs at 24 V DC and 16 relay outputs for AC or DC control loads.
CONFIGURATION NOTE
For 6ES7288-2DR32-0AA0, Siemens specifies 16 inputs, 16 relay outputs rated 2 A per point, an 8 A maximum per output common and a 180 mA backplane-bus current.
👩‍💼
