ALTIVAR PROCESS ATV900 · ATV930 VARIABLE SPEED DRIVE

ATV930D11N4

The ATV930D11N4 is a supplied Schneider Electric Altivar Process ATV930 identifier. Schneider Electric documents ATV930D11N4 as an Altivar Process ATV930 variable speed drive rated 11 kW for 380–480 V three-phase supply, with an integrated braking unit and IP21 protection.

WIDTH171 mm
HEIGHT409 mm
DEPTH236 mm
WEIGHT7.7 kg
MANUFACTURERSchneider Electric
CONDITION / WARRANTYOriginal New · One-Year Warranty
ISO CERTIFICATIONISO-Certified Product
VERIFICATION● Product photos and videos provided after inquiry
REQUEST A QUOTE
สอบถามตอนนี้
MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.
SCHNEIDER ELECTRIC ● ATV930D11N4 VARIABLE SPEED DRIVE
ALTIVAR PROCESS ATV900 DRIVES

ATV930D11N4

ALTIVAR PROCESS ATV930

Variable Speed Drive · Process and Utilities

SYSTEM ROLE
ATV930D11N4 is a supplied Altivar Process ATV930 identifier. The official ATV930D11N4 base model is a 11 kW, 380–480 V variable speed drive with braking unit and IP21 protection.
CONFIGURATION NOTE
For ATV930D11N4, verify the complete order number, 380–480 V three-phase supply, 11 kW rating, braking configuration, IP21 enclosure, control wiring and mechanical fit before replacement.
👩‍💼
WANT THE BEST PRICE?
Frida
Sales Leader 🏆
EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275
MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

SCHNEIDER ELECTRIC ↗
ATV930D11N4 VARIABLE SPEED DRIVE

Engineering data at a glance

Click “+” to expand more specifications.

POWER11 kW
SUPPLY380–480 V
PROTECTIONIP21
BRAKING UNITIncluded
Official Schneider Electric base-model data for ATV930D11N4; verify the complete order number.
Model reference ATV930D11N4 identifies an Altivar Process ATV930 drive configuration. Official base-model data supports 11 kW, 380–480 V, braking unit and IP21; verify the complete order number against the exact nameplate and order record.
General Information −
BrandSchneider Electric
ModelATV930D11N4
Product typeVariable Speed Drive
Product familyAltivar Process ATV900
Device short nameATV930
ApplicationIndustrial Process
Electrical and Drive Data ＋
Motor power11 kW (normal duty)
Rated supply380–480 V AC, 3 phase
Continuous output current23.5 A at 4 kHz
Communication and I/O ＋
Communication protocolsModbus TCP; EtherNet/IP; Modbus serial
Ethernet ports2 RJ45, 10/100 Mbit/s
Analog inputs3
Discrete inputs10
Relay outputs3
Installation and Environment ＋
ATV930D11N4 is a wall-mounted IP21 drive with forced-convection cooling. Schneider Electric specifies 171 mm width, 409 mm height, 236 mm depth, 7.7 kg product weight, vertical mounting within ±10°, and operation up to 50–60 °C with derating.
Source: Schneider Electric official product page for ATV930D11N4 and the supplied complete identifier ATV930D11N4.
FAQ

Questions Buyers Ask Most

What type of product is ATV930D11N4?＋

ATV930D11N4 is a Schneider Electric Altivar Process ATV930 variable speed drive for synchronous and asynchronous motors in industrial process applications.

What motor power and supply apply to ATV930D11N4?＋

ATV930D11N4 is rated for 11 kW normal-duty motor power and a 380–480 V AC three-phase supply.

What protection and mounting apply to ATV930D11N4?＋

ATV930D11N4 has IP21 protection and is designed for wall mounting in a vertical position within ±10° with the specified cooling clearances.

Which communication protocols are built into ATV930D11N4?＋

ATV930D11N4 supports Modbus TCP, EtherNet/IP and Modbus serial communication; Schneider Electric also lists a Profibus DP V1 option module for slot A.

What I/O is listed for ATV930D11N4?＋

ATV930D11N4 provides three analog inputs, ten discrete inputs, two analog outputs, two discrete outputs and three configurable relay outputs.

What are the dimensions and weight of ATV930D11N4?＋

ATV930D11N4 measures 171 mm wide, 409 mm high and 236 mm deep, with an official product weight of 7.7 kg.

What should be checked before replacing ATV930D11N4?＋

Before replacing ATV930D11N4, confirm the complete nameplate, motor and duty rating, supply, braking configuration, control protocol, enclosure, mounting clearances and wiring.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete order number and application details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD
OFFICIAL DATA SHEET

Schneider Electric ATV930D11N4
Official Product Data

Official Schneider Electric product data for ATV930D11N4 covers the Altivar Process ATV930 11 kW variable speed drive for 380–480 V three-phase supply with braking unit and IP21 protection.

ATV930D11N4 Official Datasheet

Open the official Schneider Electric product datasheet for ATV930D11N4 to review electrical ratings, dimensions, protection, mounting and technical characteristics.

OPEN OFFICIAL DATASHEET ↗

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

Official Schneider Electric product page and datasheet support the listed ATV930D11N4 data. Confirm the complete nameplate and installed-system configuration before replacement.

ORDER NUMBER BREAKDOWN

What the ATV930D11N4 order number identifies

The official Schneider Electric order-number structure identifies the drive family, power rating and voltage class.

PRODUCT FAMILY

ATV930

Altivar Process ATV930 variable speed drive family.

POWER RATING

D11

11 kW normal-duty motor power rating.

VOLTAGE CLASS

N4

380–480 V AC three-phase supply class.

Use the complete ATV930D11N4 order number when matching the drive to the installed motor, supply, duty rating and enclosure.
APPLICATION AREAS

Application areas for Schneider Electric ATV930D11N4

Process and UtilitiesVariable-speed control for compatible process and utilities equipment
Pump SystemsVariable-speed operation for compatible water, wastewater and process pumps
APPLICATION CENTER ATV930D11N4 Altivar Process ATV930 Variable Speed Drive
Fan and HVAC SystemsVariable-speed control for compatible fan and HVAC systems
Industrial Process LinesVariable-speed motor control for compatible industrial process lines
