GE EX2100 · EDEX DE-EXCITATION

IS200EDEXG1A

The IS200EDEXG1A is a GE EX2100 Exciter De-Excitation control board. GE Industrial Systems board instructions identify EDEX as the main board in the de-excitation module, providing SCR firing, conduction-sense feedback and voltage retention when stored generator-field energy must be removed.

PRODUCT TYPEEX2100 EDEX CONTROL BOARD
DE-EXCITATIONSCR FIRING CONTROL
SENSINGHALL EFFECT
POWER INPUTS+24 / −24 Vdc
MANUFACTURERGE
CONDITION / WARRANTYOriginal New · One-Year Warranty
ISO CERTIFICATIONISO-Certified Product
VERIFICATION● Product photos and videos provided after inquiry
REQUEST A QUOTE
สอบถามตอนนี้
MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.
GE● EX2100 EXCITER DE-EXCITATION BOARD
GE EX2100

IS200EDEXG1A

EXCITER DE-EXCITATION CONTROL BOARD

EX2100 · SCR FIRING · HALL EFFECT CONDUCTION SENSING

PRODUCT ROLE
IS200EDEXG1A is the main control board in the GE EX2100 de-excitation module.
TECHNICAL CONTEXT
IS200EDEXG1A serves as the main control board within the GE EX2100 de-excitation module. It generates the firing commands for the de-excitation SCR circuit, monitors field-current conduction through two bipolar Hall Effect sensing channels, and retains the firing voltage required to operate during a loss of incoming power. The board exchanges firing and conduction-status signals with the EXTB interface through J8 and routes SCR gate output through the DEPL connection. It can operate as a Master or Follower board to coordinate controlled dissipation of stored generator-field energy during de-excitation events.
👩‍💼
WANT THE BEST PRICE?
Frida
Sales Leader 🏆
EMAILsales5@mooreplc.comWHATSAPP+86 153 5940 8275
MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

GE EX2100 ↗
IS200EDEXG1A EX2100 EXCITER DE-EXCITATION BOARD

Engineering data at a glance

Click “+” to expand more specifications.

BOARD ROLEDe-Excitation
METHODSCR Firing
SENSINGHall Effect
INTERFACESJ8 + DEPL
The values shown summarize GE Industrial Systems GEI-100466 board-level instructions. Confirm the complete IS200EDEXG1A catalog number, installed revision and exciter configuration before replacement.
System contextUse IS200EDEXG1A with the compatible EXTB interface and configured de-excitation SCR circuit. Verify the complete catalog number, revision, jumper configuration and installed exciter arrangement before commissioning.
GENERAL INFORMATION −
BrandGE
Part numberIS200EDEXG1A
Product typeExciter De-Excitation control board
Excitation systemEX2100 Excitation Control
System roleMain board in the de-excitation module
DE-EXCITATION FUNCTIONS ＋
Board functionSCR de-excitation control
Trigger pathEXTB transfers firing commands
Conduction feedbackTwo current-sense circuits
Backup behaviorVoltage retention during power loss
Application typeGroup 1 board for SCR de-excitation
SENSING & INTERFACES ＋
Conduction sensorsHall Effect sensors
Current detectionBipolar M1 and M2 circuits
EXTB connectionJ8 six-pin locking connector
SCR gate connectionDEPL two-pin locking connector
POWER & CONFIGURATION ＋
Board power+24 V dc · 24 V return · -24 V dc
Power connectorsJ17M1 and J17M2
Board modeMaster or Follower
Anode firing setupWire-jumper selected for SCR cell and voltage
Exciter interfaceEXTB and de-excitation SCR circuit
Source: GE Industrial Systems GEI-100466, Exciter De-Excitation Board EDEX, board-level instructions for IS200EDEXG1A. No direct manufacturer-hosted exact-model PDF was confirmed publicly.
