 /GE Fanuc IC660BBS103 8-Circuit Isolated I/O Block
GE Fanuc IC660BBS103 8-Circuit Isolated I/O Block
GE Fanuc IC660BBS103 8-Circuit Isolated I/O Block
GE Fanuc IC660BBS103 8-Circuit Isolated I/O Block

GE Fanuc IC660BBS103 8-Circuit Isolated I/O Block

GE FANUC GENIUS I/O · 115 VAC/125 VDC LOW-LEAK ISOLATED I/O BLOCK WITHOUT FAILED-SWITCH DIAGNOSTIC

IC660BBS103

The IC660BBS103 is a GE Fanuc Genius I/O 115 VAC/125 VDC low-leak 8-circuit isolated I/O block without the command-state failed-switch diagnostic. Verify the exact catalog number, 93–132 VAC or 105–132 VDC operating voltage, four isolated circuit pairs, parallel-switch application requirement and Genius I/O configuration before replacement.

PRODUCT TYPE115 VAC/125 VDC LOW-LEAK ISOLATED I/O BLOCK WITHOUT FAILED-SWITCH DIAGNOSTIC
PLATFORMGenius I/O
POINTS8 isolated I/O circuits
FUNCTIONlow-leak isolated AC/DC field I/O without the command-state failed-switch diagnostic
MANUFACTURERGE Fanuc
CONDITION / WARRANTYOriginal New · One-Year Warranty
ISO CERTIFICATIONISO-Certified Product
VERIFICATION● Product photos and videos provided after inquiry
REQUEST A QUOTE
สอบถามตอนนี้
MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.
GE Fanuc ● 115 VAC/125 VDC LOW-LEAK ISOLATED I/O BLOCK WITHOUT FAILED-SWITCH DIAGNOSTIC
GE FANUC GENIUS I/O

IC660BBS103

115 VAC/125 VDC LOW-LEAK ISOLATED I/O BLOCK WITHOUT FAILED-SWITCH DIAGNOSTIC

GENIUS I/O · 8 I/O CIRCUITS · FOUR ISOLATED PAIRS

MODULE ROLE
IC660BBS103 is a GE Fanuc Genius I/O 115 VAC/125 VDC low-leak isolated I/O block without the command-state failed-switch diagnostic. It provides eight input/output circuits in four isolated pairs; verify operating voltage, application requirement, circuit configuration and field wiring before replacement.
CONFIGURATION NOTE
For IC660BBS103, confirm the exact catalog number, hardware revision, 93–132 VAC or 105–132 VDC operating voltage, parallel-switch application requirement, Genius I/O bus address, circuit input/output configuration and terminal-assembly compatibility before replacement.
👩‍💼
WANT THE BEST PRICE?
Frida
Sales Leader 🏆
EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275
ORDER NUMBER BREAKDOWN

How the IC660BBS103 Catalog Number Is Structured

IC660
Genius I/O familyLegacy GE Fanuc Genius I/O catalog prefix
BBS103
Block variant115 VAC/125 VDC low-leak isolated I/O block without the command-state failed-switch diagnostic
MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

GE Fanuc Genius I/O ↗
IC660BBS103 115 VAC/125 VDC LOW-LEAK ISOLATED I/O BLOCK WITHOUT FAILED-SWITCH DIAGNOSTIC

Engineering data at a glance

Click “+” to expand more specifications.

HEIGHT22.44 cm
WIDTH8.48 cm
DEPTH9.93 cm
WEIGHT1.8 kg
GE Fanuc documentation specifies an 8.83 x 3.34 x 3.91 inch block size, equivalent to 22.44 x 8.48 x 9.93 cm, and a weight of 4 lb (1.8 kg).
Official product verification Verify the complete model IC660BBS103, operating voltage, low-leak 8-circuit input/output configuration, parallel-switch application requirement, terminal assembly and connected Genius I/O station before ordering.
GENERAL INFORMATION −
BrandGE Fanuc
Part numberIC660BBS103
Product type115 VAC/125 VDC LOW-LEAK ISOLATED I/O BLOCK WITHOUT FAILED-SWITCH DIAGNOSTIC
Product familyGE Fanuc Genius I/O
System roleGenius I/O 115 VAC/125 VDC Low-Leak Isolated I/O Block Without Failed-Switch Diagnostic
PlatformGenius I/O
CATALOG IDENTIFICATION ＋
Catalog familyIC660 Genius I/O family
Catalog numberIC660BBS103
Replacement checkMatch the exact catalog number, block hardware revision and station configuration
ISOLATED I/O & POWER ＋
I/O circuits8 circuits in 4 isolated pairs
Operating voltage93–132 VAC or 105–132 VDC
Block-to-block isolation1500 V
Circuit arrangementFour isolated pairs · two circuits per pair
Output currentAC: 2 A RMS · DC: 2 A resistive (1 A inductive) · maximum output leakage 7 mA AC / 2 mA DC · Command-state failed-switch diagnostic not provided
ENVIRONMENTAL & PHYSICAL ＋
Operating environment: 22.44 x 8.48 x 9.93 cm; 1.8 kg; 0°C to +60°C; 5% to 95% RH, non-condensing
Source: GE Fanuc GFK-0040E identifies IC660BBS103 as the 115 VAC/125 VDC low-leak 8-circuit isolated I/O block without the command-state failed-switch diagnostic.
FAQ

Questions Buyers Ask Most

What does IC660BBS103 identify?＋

IC660BBS103 is a GE Fanuc Genius I/O low-leak isolated I/O block with eight circuits in four isolated pairs without the command-state failed-switch diagnostic.

Why does IC660BBS103 omit the command-state failed-switch diagnostic?＋

IC660BBS103 ignores differences between an output command and the internal switch feedback state, which helps avoid false messages when a manual or external switch is wired in parallel. Internal switch failures may still be reported.

How are the circuits on IC660BBS103 arranged?＋

IC660BBS103 provides eight input/output circuits in four isolated pairs, with two circuits sharing each isolated power group.

What operating voltage does IC660BBS103 use?＋

IC660BBS103 operates from 93–132 VAC or 105–132 VDC, matching the documented 115 VAC/125 VDC isolated I/O application.

What must be confirmed before replacing IC660BBS103?＋

For IC660BBS103, confirm the exact catalog number, low-leak hardware revision, operating voltage, parallel-switch application requirement, input/output assignment, isolated-pair wiring, bus configuration and terminal-assembly compatibility.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete order number and application details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD
DATA SHEET

Product Information for
IC660BBS103

GE Fanuc publication GFK-0040E covers IC660BBS103 installation, specifications, configuration and diagnostics.

Official datasheet status

GE Fanuc datasheet GFK-0040E identifies IC660BBS103 as the 115 VAC/125 VDC low-leak 8-circuit isolated I/O block without the command-state failed-switch diagnostic. Verify the exact catalog number and terminal-assembly compatibility before replacement.

OPEN GFK-0040E

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

Use GFK-0040E for the documented IC660BBS103 characteristics and confirm the complete catalog number, hardware revision and terminal assembly for replacement verification.

GE FANUC GENIUS I/O RELATIONSHIP

How IC660BBS103 Fits into a Genius I/O Station

GE Fanuc is the manufacturer brand; GE Fanuc Genius I/O is the product family; and IC660BBS103 is the 115 VAC/125 VDC low-leak 8-circuit isolated I/O block without the command-state failed-switch diagnostic for the station.

GE Fanuc · BRAND
GE Fanuc Genius I/O115 VAC/125 VDC Low-Leak Isolated I/O Block
SYSTEM ROLE

115 VAC/125 VDC Low-Leak Isolated I/O Block

Connects eight low-leak isolated AC/DC field I/O circuits to the Genius I/O network and supports applications with manual or external switches wired in parallel with outputs; verify operating voltage and field wiring before replacement.

MODULE / CONFIGURATION

8 I/O circuits · 4 isolated pairs

The block provides eight input/output circuits in four isolated pairs, operates from 93–132 VAC or 105–132 VDC and omits the command-state failed-switch diagnostic.

ORDER DATA

IC660BBS103 · 115 VAC/125 VDC Low-Leak Isolated I/O Block

Do not substitute another module without checking the exact catalog number, hardware revision, operating voltage, isolated-pair wiring and station configuration.

System relationship: verify the exact catalog number, hardware revision, operating voltage, circuit assignments, terminal assembly and connected Genius I/O network configuration.
APPLICATION AREAS

Application map for IC660BBS103

Low-Leak Isolated AC/DC Field I/OConnect 115 VAC or 125 VDC field devices through four low-leak isolated circuit pairs
Parallel Field SwitchingUse this version where a manual or external switch may be wired in parallel with an output
APPLICATION CENTER IC660BBS103 IC660BBS103 · 115 VAC/125 VDC Low-Leak Isolated I/O Block
Independent Circuit GroupsUse four isolated pairs where field-circuit separation is required
Genius I/O StationsIntegrate isolated discrete field circuits on a Genius I/O network.
