GE Fanuc IC660BBS102 Genius I/O Block
GE Fanuc IC660BBS102 Genius I/O Block
GE Fanuc IC660BBS102 Genius I/O Block

GE Fanuc IC660BBS102 Genius I/O Block

GE FANUC GENIUS I/O · 115 VAC/125 VDC LOW-LEAK ISOLATED I/O BLOCK WITH FAILED-SWITCH DIAGNOSTICS

IC660BBS102

The IC660BBS102 is a GE Fanuc Genius I/O 115 VAC/125 VDC low-leak 8-circuit isolated I/O block with failed-switch diagnostics. Verify the exact catalog number, 93–132 VAC or 105–132 VDC operating voltage, four isolated circuit pairs, failed-switch diagnostic requirement and Genius I/O configuration before replacement.

PRODUCT TYPE115 VAC/125 VDC LOW-LEAK ISOLATED I/O BLOCK WITH FAILED-SWITCH DIAGNOSTICS
PLATFORMGenius I/O
POINTS8 isolated I/O circuits
FUNCTIONlow-leak isolated AC/DC field I/O with failed-switch diagnostics
MANUFACTURERGE Fanuc
CONDITION / WARRANTYOriginal New · One-Year Warranty
ISO CERTIFICATIONISO-Certified Product
VERIFICATION● Product photos and videos provided after inquiry
REQUEST A QUOTE
สอบถามตอนนี้
MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.
GE Fanuc ● 115 VAC/125 VDC LOW-LEAK ISOLATED I/O BLOCK WITH FAILED-SWITCH DIAGNOSTICS
GE FANUC GENIUS I/O

IC660BBS102

115 VAC/125 VDC LOW-LEAK ISOLATED I/O BLOCK WITH FAILED-SWITCH DIAGNOSTICS

GENIUS I/O · 8 I/O CIRCUITS · FOUR ISOLATED PAIRS

MODULE ROLE
IC660BBS102 is a GE Fanuc Genius I/O 115 VAC/125 VDC low-leak isolated I/O block with failed-switch diagnostics. It provides eight input/output circuits in four isolated pairs; verify operating voltage, diagnostic requirement, circuit configuration and field wiring before replacement.
CONFIGURATION NOTE
For IC660BBS102, confirm the exact catalog number, hardware revision, 93–132 VAC or 105–132 VDC operating voltage, failed-switch diagnostic requirement, Genius I/O bus address, circuit input/output configuration and terminal-assembly compatibility before replacement.
👩‍💼
WANT THE BEST PRICE?
Frida
Sales Leader 🏆
EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275
ORDER NUMBER BREAKDOWN

How the IC660BBS102 Catalog Number Is Structured

IC660
Genius I/O familyLegacy GE Fanuc Genius I/O catalog prefix
BBS102
Block variant115 VAC/125 VDC low-leak isolated I/O block with failed-switch diagnostics
MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

GE Fanuc Genius I/O ↗
IC660BBS102 115 VAC/125 VDC LOW-LEAK ISOLATED I/O BLOCK WITH FAILED-SWITCH DIAGNOSTICS

Engineering data at a glance

Click “+” to expand more specifications.

HEIGHT22.44 cm
WIDTH8.48 cm
DEPTH9.93 cm
WEIGHT1.8 kg
GE Fanuc documentation specifies an 8.83 x 3.34 x 3.91 inch block size, equivalent to 22.44 x 8.48 x 9.93 cm, and a weight of 4 lb (1.8 kg).
Official product verification Verify the complete model IC660BBS102, operating voltage, low-leak 8-circuit input/output configuration, failed-switch diagnostic requirement, terminal assembly and connected Genius I/O station before ordering.
GENERAL INFORMATION −
BrandGE Fanuc
Part numberIC660BBS102
Product type115 VAC/125 VDC LOW-LEAK ISOLATED I/O BLOCK WITH FAILED-SWITCH DIAGNOSTICS
Product familyGE Fanuc Genius I/O
System roleGenius I/O 115 VAC/125 VDC Low-Leak Isolated I/O Block with Failed-Switch Diagnostics
PlatformGenius I/O
CATALOG IDENTIFICATION ＋
Catalog familyIC660 Genius I/O family
Catalog numberIC660BBS102
Replacement checkMatch the exact catalog number, block hardware revision and station configuration
ISOLATED I/O & POWER ＋
I/O circuits8 circuits in 4 isolated pairs
Operating voltage93–132 VAC or 105–132 VDC
Block-to-block isolation1500 V
Circuit arrangementFour isolated pairs · two circuits per pair
Output currentAC: 2 A RMS · DC: 2 A resistive (1 A inductive) · maximum output leakage 7 mA AC / 2 mA DC · Failed-switch diagnostic provided
ENVIRONMENTAL & PHYSICAL ＋
Operating environment: 22.44 x 8.48 x 9.93 cm; 1.8 kg; 0°C to +60°C; 5% to 95% RH, non-condensing
Source: GE Fanuc GFK-0040E identifies IC660BBS102 as the 115 VAC/125 VDC low-leak 8-circuit isolated I/O block with failed-switch diagnostics.
FAQ

Questions Buyers Ask Most

What does IC660BBS102 identify?＋

IC660BBS102 is a GE Fanuc Genius I/O low-leak isolated I/O block with eight circuits in four isolated pairs and failed-switch diagnostics.

What does the failed-switch diagnostic on IC660BBS102 report?＋

IC660BBS102 reports a Failed Switch diagnostic when an output command does not match the feedback state of the block's internal switch. Verify field wiring before interpreting the fault.

How are the circuits on IC660BBS102 arranged?＋

IC660BBS102 provides eight input/output circuits in four isolated pairs, with two circuits sharing each isolated power group.

What operating voltage does IC660BBS102 use?＋

IC660BBS102 operates from 93–132 VAC or 105–132 VDC, matching the documented 115 VAC/125 VDC isolated I/O application.

What must be confirmed before replacing IC660BBS102?＋

For IC660BBS102, confirm the exact catalog number, low-leak hardware revision, operating voltage, failed-switch diagnostic requirement, input/output assignment, isolated-pair wiring, bus configuration and terminal-assembly compatibility.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete order number and application details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD
DATA SHEET

Product Information for
IC660BBS102

GE Fanuc publication GFK-0040E covers IC660BBS102 installation, specifications, configuration and diagnostics.

Official datasheet status

GE Fanuc datasheet GFK-0040E identifies IC660BBS102 as the 115 VAC/125 VDC low-leak 8-circuit isolated I/O block with failed-switch diagnostics. Verify the exact catalog number and terminal-assembly compatibility before replacement.

OPEN GFK-0040E

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

Use GFK-0040E for the documented IC660BBS102 characteristics and confirm the complete catalog number, hardware revision and terminal assembly for replacement verification.

GE FANUC GENIUS I/O RELATIONSHIP

How IC660BBS102 Fits into a Genius I/O Station

GE Fanuc is the manufacturer brand; GE Fanuc Genius I/O is the product family; and IC660BBS102 is the 115 VAC/125 VDC low-leak 8-circuit isolated I/O block with failed-switch diagnostics for the station.

GE Fanuc · BRAND
GE Fanuc Genius I/O115 VAC/125 VDC Low-Leak Isolated I/O Block
SYSTEM ROLE

115 VAC/125 VDC Low-Leak Isolated I/O Block

Connects eight low-leak isolated AC/DC field I/O circuits to the Genius I/O network and reports failed-switch mismatches; verify operating voltage and field wiring before replacement.

MODULE / CONFIGURATION

8 I/O circuits · 4 isolated pairs

The block provides eight input/output circuits in four isolated pairs, operates from 93–132 VAC or 105–132 VDC and includes failed-switch diagnostics.

ORDER DATA

IC660BBS102 · 115 VAC/125 VDC Low-Leak Isolated I/O Block

Do not substitute another module without checking the exact catalog number, hardware revision, operating voltage, isolated-pair wiring and station configuration.

System relationship: verify the exact catalog number, hardware revision, operating voltage, circuit assignments, terminal assembly and connected Genius I/O network configuration.
APPLICATION AREAS

Application map for IC660BBS102

Low-Leak Isolated AC/DC Field I/OConnect 115 VAC or 125 VDC field devices through four low-leak isolated circuit pairs
Failed-Switch DiagnosticsMonitor commanded-versus-feedback mismatch on output circuits while applying the eight circuits as required
APPLICATION CENTER IC660BBS102 IC660BBS102 · 115 VAC/125 VDC Low-Leak Isolated I/O Block
Independent Circuit GroupsUse four isolated pairs where field-circuit separation is required
Genius I/O StationsIntegrate isolated discrete field circuits on a Genius I/O network.
