 /Bently Nevada 990-05-XX-03-00 Vibration Transmitter
Bently Nevada 990-05-XX-03-00 Vibration Transmitter
Bently Nevada 990-05-XX-03-00 Vibration Transmitter
Bently Nevada 990-05-XX-03-00 Vibration Transmitter

Bently Nevada 990-05-XX-03-00 Vibration Transmitter

990 SERIES · VIBRATION TRANSMITTER

990-05-XX-03-00

990-05-XX-03-00 — A Bently Nevada 990 Vibration Transmitter with 0 to 5 mil pp full scale, XX system-length code, DIN clips and screws, no agency approval requirement.

FULL SCALE0–5 MIL PP
SYSTEM LENGTHXX · CONFIRM
MOUNTINGDIN CLIPS AND SCREWS
APPROVALNOT REQUIRED
MANUFACTURERBently Nevada · Baker Hughes
CONDITION / WARRANTYOriginal New · One-Year Warranty
ISO CERTIFICATIONISO-Certified Product
VERIFICATION● Product photos and videos provided after inquiry
REQUEST A QUOTE
สอบถามตอนนี้
MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.
BENTLY NEVADA ● 990 VIBRATION TRANSMITTER
990 VIBRATION TRANSMITTER

990-05-XX-03-00

0–5 mil pp full scale · XX system-length code · DIN clips and screws · No agency approval

990 Vibration Transmitter

VIBRATION TRANSMITTER ROLE
990-05-XX-03-00 — This two-wire, loop-powered 990 transmitter accepts one matched 3300 NSv proximity probe and extension cable, then provides a proportional 4 to 20 mA vibration signal for a machinery control system.
CONFIGURATION NOTE
990 identifies the vibration transmitter; 05 specifies 0 to 5 mil pp full scale, XX is the supplied system-length code and must be confirmed for this modification, 03 specifies DIN clips and screws, and 00 specifies that agency approval is not required.
👩‍💼
WANT THE BEST PRICE?
Frida
Sales Leader 🏆
EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275
CONFIGURATION DECODING

Model code at a glance

05
Full-scale option0 to 5 mil pp
XX
System-length codeConfirm exact configured length
03
Mounting optionDIN clips and screws
00
Agency approvalNot required
MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

Bently Nevada Official Site ↗
990 VIBRATION TRANSMITTER

Engineering data at a glance

Click “+” to expand more specifications.

FULL SCALE0–5 MIL PP
SYSTEM LENGTHXX · CONFIRM
MOUNTINGDIN CLIPS AND SCREWS
APPROVALNOT REQUIRED
Configuration from manufacturer ordering data.
Configuration check Confirm the complete 990-05-XX-03-00 order code, exact configured system length, mounting option, approval requirement and matched 3300 NSv components before ordering.
General Information −
BrandBently Nevada
Part number990-05-XX-03-00
Product type990 Vibration Transmitter
Product family990 Series
Full-scale range0–5 mil pp
Order Configuration ＋
System-length codeXX · confirm exact configured length
Mounting optionDIN clips and screws
Agency approval00 · Not required
Electrical Interface ＋
Power requirement+12 to +35 Vdc at transmitter terminal
Signal output4 to 20 mAdc
Loop configurationTwo-wire, loop-powered
Compatible inputOne 3300 NSv proximity probe and extension cable
Performance and Limits ＋
The 990 provides a proportional 4 to 20 mA output over its configured full-scale range. Published family specifications include ±1.5% loop accuracy, 5 Hz to 6,000 Hz frequency response, and transmitter operating temperature from -35°C to +85°C.
Source: Bently Nevada 990 Vibration Transmitter Datasheet, Part Number 141612, Rev. Y. Published family data supports the 990 series; the public ordering table does not decode the supplied XX system-length placeholder, so confirm it against the product nameplate or manufacturer documentation.
FAQ

Questions Buyers Ask Most

What is 990-05-XX-03-00 used for?＋

990-05-XX-03-00 is a Bently Nevada 990 vibration transmitter configuration with 0 to 5 mil pp full scale, DIN clips and screws, no agency approval requirement, and an XX system-length code that requires confirmation.

What does the 990-05-XX-03-00 code specify?＋

For 990-05-XX-03-00, 990 identifies the transmitter; 05 is the 0 to 5 mil pp full-scale option, XX is the supplied system-length code, 03 is DIN clips and screws mounting, and 00 means agency approval is not required.

Can 990-05-XX-03-00 be substituted with a similar part number?＋

Do not substitute 990-05-XX-03-00 by appearance or family name alone. Compare the full-scale range, exact system length, mounting option, approval requirement and matched 3300 NSv components.

What do the 05, XX, 03 and 00 options on 990-05-XX-03-00 specify?＋

990-05-XX-03-00 uses 0 to 5 mil pp full scale, a supplied XX system-length code that must be confirmed, DIN clips and screws and no agency approval requirement.

What should I provide for a 990-05-XX-03-00 quotation?＋

Send the complete 990-05-XX-03-00 nameplate, quantity, exact matched probe and cable details, required approvals, and delivery destination.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete transmitter nameplate, including 990-05-XX-03-00, plus matched probe/cable details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD
DATA SHEET

Manuals and Official References for
990-05-XX-03-00

Official manufacturer documentation for the Bently Nevada 990 Vibration Transmitter and its matched 3300 NSv proximity transducer system.

Official manufacturer datasheet

Bently Nevada Datasheet 141612 identifies the 990 Vibration Transmitter and its public ordering options. For this supplied identity, 05 specifies 0 to 5 mil pp full scale, 03 specifies DIN clips and screws, and 00 means agency approval is not required. Confirm the XX system-length code from the nameplate or manufacturer documentation.

VIEW OFFICIAL DATASHEET

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

Technical statements and published ordering-code meanings use Bently Nevada 990 Vibration Transmitter Datasheet, Part Number 141612, Rev. Y. The public ordering table does not decode XX.

990 VIBRATION TRANSMITTER CONNECTION

How 990-05-XX-03-00 Fits into the 990 Vibration Transmitter

Bently Nevada is the manufacturer. 990-05-XX-03-00 is a two-wire, loop-powered 990 vibration transmitter configuration with 0 to 5 mil pp full scale and DIN clips and screws. It accepts the matched 3300 NSv proximity probe and extension cable and provides a proportional 4 to 20 mA vibration signal.

Bently Nevada · BRAND
Bently Nevada 990 SeriesPRODUCT FAMILY · VIBRATION TRANSMITTER
MEASUREMENT INPUT

Matched 3300 NSv System

One matched 3300 NSv proximity probe and extension cable provide the vibration input to the 990 transmitter.

TRANSMITTER MOUNT

DIN Clips and Mounting Screws

The 03 option specifies DIN clips and screws for this 990 configuration.

SYSTEM LENGTH CODE

XX · Confirm

The public 990 ordering table lists 50 and 70 system-length options; confirm the supplied XX code and exact configured system length before ordering.

System relationship: use the transmitter only with the matched 3300 NSv probe and extension cable for the confirmed system length.
APPLICATION AREAS

Functions and integration points for 990-05-XX-03-00

Loop-Powered OutputProvides a proportional 4 to 20 mA vibration signal to compatible plant monitoring and control systems.
Diagnostic PROX OUTProvides a non-isolated dynamic vibration and gap-voltage signal for diagnostics; use the manufacturer-recommended isolation arrangement with grounded AC-powered test equipment.
APPLICATION CENTER 990-05-XX-03-00 990 Vibration Transmitter
Fault-Aware Signal PathThe Not OK/signal-defeat circuit drives the signal below 3.6 mA when a Not OK condition occurs.
Matched Machinery MonitoringSupports overall vibration measurement on compatible machinery when installed with the correct matched 3300 NSv probe and extension cable.
